1/10 R/C Manta Ray (2018)

Hip Hip, Hoo-Ray!
This re-release of the Manta Ray is certainly news to celebrate for fans of Tamiya vintage 4WD buggy models!

The body - inspired by the watergoing ray of the natural world - is still a classic nearly 30 years on from its original release in 1990; it and the large rear wing are molded in lightweight and tough polycarbonate. Stylish dish type wheels are paired with spike tires for superlative grip on- or off-road.

A Rugged 4WD Chassis
This kit"s 4WD chassis is based around a bathtub frame with honeycomb rib pattern for excellent rigidity, and which also facilitates a low center of gravity thanks to a low attachment position for the battery pack.

Its 4-wheel independent double wishbone suspension employs CVA oil dampers, while lightweight and durable hollow lower arms feature a smooth design to discourage dirt from sticking to them. Differential gears are contained in sealed gearboxes, each with a quick-access maintenance hatch. The 3-piece steering tie-rod gives sharp response, and ball adjusters allow easy altering of toe angle.

Specifications

• Length: 395mm, Width: 250mm, Height: 145mm
• Wheelbase: 270mm
• Weight (excluding R/C equipment and battery pack): 1,100g
• Tread: 207mm (Front & Rear)
• Bathtub-type Chassis Frame
• Shaft-Driven 4WD
• Front/Rear 3-Bevel Differentials
• 3-Piece Steering Tie-Rod
• 4-Wheel Double Wishbone Suspension
• Tire Width/Diameter: 40/84mm (Front & Rear)
• CVA Short Oil Shock Units
• Gear Ratio=8.59:1 (with kit-included 21T pinion gear)
• Type 540 Motor
• Requires an Electronic Speed Controller (sold separately)
